Dixie Chopper 903277DC

Dixie Chopper Engine Kit 36 HP Brigs & Stratton Vanguard with Manual Clutch

Replace the Engine on your Commercial or Industrial Lawn Mower with a Briggs & Stratton Engine!

Part # 903277DC

For Generac 27 HP & 33 HP

*** For Manual Clutch Models ***

This engine offers an immediate power upgrade from the Generac 27 HP & 33 HP. It is a a top-of-the-line engine for commercial mowers and heavy duty industrial and construction equipment. This replacement kit offers a more powerful and easy to install alternative.

Fits the Following Models - May Fit Additional Models & Brands Which Are NOT Listed Below.

---

Compatible Dixie Chopper Models

Dixie Chopper Classic Dixie Chopper X Caliber

Replaces the following Engines

Generac 27 HP Engines Generac 33 HP Engines Vangaurd 36 HP

Dixie Chopper Engine Kit Includes

(1) Muffler-Briggs, Vanguard, 993 cc, Dual (Part # 600534) (1) Engine-Briggs, 36HP, Vanguard, 993 cc (Part # 600530) (1) Bracket-Cooler Hydraulic Briggs 36, Black (Part # 200766DC) (2) Nut-3/8-16 Flange Whiz, Clear Zinc (Part # N-108) (2) Bolt - 3/8-16x1-3/4 HHCS PT Gr.5, Clear Zinc (Part # B-124) (1) Clamp-1/2 Rubber Coated Clamp(Part # C-112) (1) Harness-Wiring Briggs 36HP Adapter (Part # 500191) (1) Fitting-Adapter M14X1.5Male to 3/8" NPT Female (Part # 600564) (1) Hose-Drain Pan Oil W/E-Z Valve (Part # 600436) (1) Spacer-Machined 2ODX1.155ID Yellow Zinc (Part # 600425) (1) 5" x 6" DBL Deep Groove (Part # 9907500x600d) (1) Washer-1-1/8x1-3/4x1/8 Flat, Plain (Part # W-145) (1) Spacer-Crank Engine Clear Zinc (Part # 600477) (1) Spacer-.460IDX2.00ODX.25Th Zinc Plated (Part # 600422) (1) Washer-7/16x1-1/2x.108 Belleville, SS (Part # W-144) (1) Washer-7/16 Flat, Clear Zinc (Part # W-166) (1) Bolt-7/16-20x1-1/2 HHCS FT Gr.5, Clear Zinc (Part # B-328)
