Dixie
Chopper Engine Kit 36 HP Brigs & Stratton Vanguard with Manual Clutch
Engines
Replace the Engine on your Commercial or Industrial Lawn Mower with a Briggs
& Stratton Engine!
Part # 902941
Replaces: Generac 27 HP & 33 HP Engines
& Vanguard 36 HP Engines
*** For Electric Clutch Models ***
*** Can be used
with Electric Clutch with Modifications ***
This
engine offers an immediate power upgrade from the Generac 27 HP & 33 HP. It
is a top-of-the-line engine for commercial mowers and heavy duty industrial and
construction equipment. This replacement kit offers a more powerful and easy to
install alternative.
|
Compatible
Dixie Chopper Models |
|
Dixie Chopper Classic |
|
Replaces the following Engines |
|
Generac 27 HP Engines |
|
Dixie
Chopper Engine Kit Includes |
|
(1) Bracket-Cooler Hydraulic Briggs
36, Black (Part # 200766) (1) Pulley - 4.867 EDB X 1.125 Bore
(Part # 200911) (1) Guard - Crash Bolt On (Part #
400519) (1) Bracket-LH Mount Crash Guard
Black (Part # 401111) (1) Bracket-RH Mount Crash Guard
Black (Part # 401112) (1) Hose-Drain Pan Oil W/E-Z Valve
(Part # 600436) (1) Muffler-Briggs, Vanguard, 993
cc, Dual (Part # 600534) (1) Fitting-Adapter M14X1.5Male to
3/8" NPT Female (Part # 600564) (1) Bracket-Brace RH Roll Bar (Part
# 902968) (1) Bracket-Brace LH Roll Bar (Part
# 902969) (4) Bolt - 3/8-16x3/4 CARR FT Gr.5
(Part # B-110) (2) Bolt - 3/8-16x1-3/4 HHCS PT Gr.5
(Part # B-124) (4) Bolt - 3/8-16x3/4 HHCS FT Gr.5
(Part # B-137) (1) Bolt-7/16-20X2-1/2 HHCS PT THL
GR5 (Part # B-467) (1) Clamp-1/2 Rubber Coated Clamp
(Part # C-112) (1) Harness-Wiring Briggs 36 HP
(Part # 500191) (1) Engine-Briggs, 36 HP, Vanguard,
993cc (Part # 600530) (2) Nut-3/8-16 Flange Whiz (Part #
N-108) (8) Nut-3/8-16 Flange Nyloc
Gr.A(Part # N-216) (1) Washer-7/16x1-1/2x.108
Belleville (Part # W-144) (1) Washer-1-1/8x1-3/4x1/8 Flat
(Part # W-145) (4) Washer-M10 Flat (Part # W-160) (1) Washer-7/16 Flat (Part # W-166) |
